Product Specs

Product Dimension:	Length : 8.8 in / 223 mm  Width : 5 in / 128 mm Height : 3.2 in / 82 mm
Product Weight:	6.3 lb / 2880 g
Input:	100-120VAC, 50-60Hz, 600W
Output:	6.6VDC 26A MAX, 13.2
Charging Voltage:	6VDC, 12VDC, 24VDC
Charging Current:	26A/5A (6VDC), 26A/5A (12VDC), 13A/5A (24VDC)
Reverse Current:	<5mA
Low Voltage Detection:	3.75V (6VDC), 3.75V (12VDC), 3.75V (24VDC)
Low Voltage Detection (Push Mode):	0.5V (6VDC), 0.5V (12VDC), 0.5V (24VDC)
Operating Temperature:	32°F up to 104°F / 0°C up to 40°C
Storage Temperature:	-4°F up to 140°F / -20°C up to 60°C
Battery Types:	Standard (Wet cell / Flooded, SLA & Maintenance Free) AGM, GEL, Lithium-ion (incl. LiFePO4)
Fuse:	Ring Terminals include 40A Fuse
Battery Capacity:	Up to 1000Ah, maintains all battery sizes
IP Rating:	IP68; Water-resistant
Model Number:	LM58277-60/6 (UPC 643334582776)
